Ag-Bag LX1214 User Manual
Page 189
Description
Quantity
Part No.
Item
Adapter, 1/2 M JIC To 1/2 MPT
6
07.17862
1
Union: Adj Thd O-Ring 3/4-16
2
09.74147
2
Adapter, -08 ORB x 1/2 M JIC
6
09.74155
3
Coupler - Quick 1/2 Female Body
1
21.00361
4
Coupler - Quick 1/2 Male Body
1
21.00362
5
Dust Cap, 1/2 in.
1
32.03084
6
Dust Plug, 1/2 in.
1
32.03085
7
Hyd Cylinder, 4 in. x 14 in. ORB
2
42.0800723
8
Pin, Clevis
4
42.0000686
8a
Switch: Tunnel Door
1
42.0802249
9
Manifold, Cylinder Check
1
42.1212008
10
Valve, Flow Divider 1/2 in. NPT
2
42.1541109.8
11
Valve, PO Check
1
42.1541795
12
Washer - Flat 1/4 in. SAE Yellow Zinc
2
900493
13
Nut: Hex Nylok Cntr 1/4 In.
2
904092
14
Washer: Stainless Steel Flat 1/4 In.
2
907234
15
Nut: Hex Stainless Steel Nylok 1/4-20
2
907389
16
Cotter Pin, 3/16 x 2 Stainless Steel
4
907427
17
Hhdblt, 1/4-20 x 2-1/2 Stainless Steel
2
907482
18
Hhdnut, #10-24 Nylock Stainless Steel
2
907621
19
Btnhdblt, #10-24 x 1-1/2 Stainless Steel
2
907637
20
Hhdblt - G5 1/4-20 x 4-1/4
2
907825
21
Kit: Seal Hydraulic Cylinder
1
42.0800715
22
LX1214
- 189 -
42.0802220A Issue Date: 08/14
Section 7
7.11 Asm: LX1214 Tunnel CO Hydraulics
