01 planetary cooling pump assembly – Ag-Bag LX1214 User Manual
Page 217
Description
Quantity
Part No.
Item
Connector - 1/2bspp x -12mjic
1
908133
1
O-Ring - M10 x 1 W/retainer
1
908132
2
Adapter, -12 Mjic x -16 Bspp
1
908092
3
Hhdnut - Nylon Lk Flng 3/8-16 Yellow Zinc
4
907779
4
Connector: 37d Flare-ORB 7/8-14
1
40.00147
5
Hhdnut - Nylon Lk 1/2-13
4
906401
6
Hhdblt, 1/4-20 x 3/4 Gr 5
2
904863
7
Hhdblt - G5 1/2-13unc x 1-1/4 in.
4
902928
8
Hhdblt, Gr 5, 3/8-16 x 1-1/4
4
902367
9
Washer - Lock 1/4 in.
2
900502
10
Base - Filter O-Ring
1
42.1541757
11
Elbow, 45° 12 Mjic x 12 ORB
1
42.1540623
12
Plug, Hex Head 1/4 Mp
1
42.1540405
13
Filter - Hydraulic P551553
1
42.1540167
14
Check Valve, 5 Psi
1
42.0801302
15
Cap, -12 Jic W/ 10mm Port
1
42.0800894
16
Valve, Relief Cartridge
1
42.0800790
17
Motor - Hyd 24cc Plntry Cooler
1
42.0800733.5
18
Seal Kit for Item 18
1
42.0800800
18a
Key: Motor Shaft
1
42.0801417
18b
Mount - Pump/motor
1
42.0800517
19
Coupler - Spider
1
42.0800436
20
Coupler - Jaw
2
42.0800435
21
Sensor, Temperature
1
42.0800272
22
Pump - Hyd Plntry Cooler
1
42.0800250.5
23
Seal Kit for Item 23
1
42.0800799
23a
Valve, Relief Body
1
32.60249
24
Adapter, 3/4 F Jic To 1/4 M Jic
1
32.04386
25
Tee, -12 ORB Run x 3/4 Mjic
1
32.02641
26
Tee, 3/4 Swivel Outlet Jic
1
32.01957
27
Adapter, -12 ORB x 3/4 Jic Swivel
1
32.01956
28
Adapter, 3/4 F Jic To 1/2 M Jic
1
32.01948
29
Tee, 3/4 Swivel Run 37 Flare
1
32.01945
30
Adapter, -12 ORB x 1/2 M Jic
1
32.01940
31
Connctr, 12 Orb/12 ORB Str
1
21.00349ZJ
32
Adapter, -12 ORB x 3/4 M Jic
2
09.74127
33
Elbow, 90d 37° Flare 3/4
1
09.74125
34
Elbow, -12 ORB x -08 Mjic
1
07.17943
35
Adapter, -06 ORB x 3/8 M Jic
1
07.17911
36
LX1214
- 217 -
42.0802220A Issue Date: 08/14
Section 8
8.01 Planetary Cooling Pump Assembly
