07 electrical connectors – Ag-Bag LX1214 User Manual
Page 255
Description
Quantity
Part No.
Item
Socket, Deutsch, 16/18 Ga
AR
21.01012
1
Socket, Deutsch, 14 Ga
AR
21.01013
2
Pin, Deutsch, 14 Ga
AR
21.01014
3
Pin, Deutsch, 16/18 Ga
AR
21.01015
4
Plug, Deutsch, 2-Socket
AR
21.22531
5
Receptacle, Deutsch, 2 Pin
AR
21.22532
6
Lock, Deutsch, 2 Pin Receptacle
AR
21.22542
7
Lock, Deutsch, 2 Socket Plug
AR
21.22543
8
Connector, Deutsch, 3 Socket
AR
21.01002
9
Plug, Deutsch Cavity
AR
21.22579
10
Receptacle, Deutsch, 31 Pin (Plastic)
AR
21.00962
11
Plug, Deutsch, 31 Socket (Plastic)
AR
21.00963
12
Connector, 23 Pos HD Deutsch Plug
AR
21.22682
13
Connector, 23 Pos HD Series, Deutsch Receptacle
AR
21.22683
14
Receptacle, Deutsch 23 Pin (Plastic)
AR
21.22725
15
Plug, Deutsch 23 Socket (Plastic)
AR
21.22726
16
Lockwasher, 1-11/16 in.
AR
21.20126
17
Nut, 1-11/16-18
AR
21.20127
18
Cap, Deutsch Plug
AR
21.22723
19
Cap, Deutsch Receptacle
AR
21.22724
20
Plug, Deutsch, 8 Socket
AR
21.22538
21
Receptacle, Deutsch, 8 Pin
AR
21.22539
22
Lock, Deutsch, 8 Pin Receptacle
AR
21.22550
23
Lock, Deutsch, 8 Socket Plug
AR
21.22551
24
Receptacle, Deutsch 3 Pin
AR
21.22533
25
Lock, Deutsch, 12 Socket Plug
AR
21.22553
26
Lock, Deutsch, 12 Pin Receptacle
AR
21.22552
27
Plug, Deutsch, 12 Socket
AR
21.22540
28
Receptacle, Deutsch, 12 Pin
AR
21.22541
29
Lock, Deutsch, 3 Socket Plug
AR
21.22545
30
Lock, Deutsch, 3 Pin Receptacle
AR
21.22544
31
Lock, Deutsch, 4 Socket Plug
AR
21.22547
32
Lock, Deutsch, 4 Pin Receptacle
AR
21.22546
33
Plug, Deutsch, 4 Socket
AR
21.22534
34
Receptacle, Deutsch, 4 Pin
AR
21.22535
35
Lock, Deutsch, 6 Socket Plug
AR
21.22549
36
Lock, Deutsch, 6 Pin Receptacle
AR
21.22548
37
Plug, Deutsch, 6 Socket
AR
21.22536
38
Receptacle, Deutsch, 6 Pin
AR
21.22537
39
Receptacle, Y
AR
21.30313
40
Terminating Resistor, Deutsch
AR
32.60886
41
LX1214
- 255 -
42.0802220A Issue Date: 08/14
Section 9
9.07 Electrical Connectors
