03 hydraulic jack assembly – Ag-Bag LX1214 User Manual
Page 267
Description
Quantity
Part No.
Item
Elbow, -08 ORB x 1/2 in. MJIC
8
09.74145
1
Adapter, -08 ORB x 1/2 in. MJIC
3
09.74155
2
Pin, Deutsch 14 Ga
3
21.01014
3
Boot, Green Toggle Switch
1
21.21460
4
Receptacle, Deutsch 3 Pin
1
21.22533
5
Lock, Deutsch 3 Pin Receptacle
1
21.22544
6
Switch, 3 Wire Cruise
1
32.00274
7
Clamp Plate, Tube
1
32.02002
8
Hydraulic Cylinder, 4 in. x 24 in. ORB
1
42.0800722
9
Pin, Clevis
2
42.0000686
9a
Seal Kit, 24 in. Cylinder
1
42.0800715
9b
Hydraulic Cylinder, 4 in. x 14 in. ORB
1
42.0800723
10
Pin, Clevis
2
42.0000686
10a
Seal Kit, 14 in. Cylinder
1
42.0800715
10b
Orifice, -8 ORB One Way (.059)
4
42.0901411
11
Decal, Up/Down Switch
2
42.1100046
12
Jack Base, Hydraulic Engine End
1
42.1212015
13
Jack Base, Hydraulic Cab End
1
42.1212016
14
Connector, -08 MORB x -08 MJIC EX
1
42.1540581
15
Washer, Flat, 1/4 in. Stainless Steel
1
907234
16
Cotter Pin, 3/16 x 2 in. Stainless Steel
4
907427
17
Bolt, Hex, 1/4-20 x 1-1/2 in. Stainless Steel
1
907458
18
PO Check Valve, Double, (-8 ORB)
2
907912
19
Clamp, Twin, .625 in. I.D. Smooth
1
908008
20
LX1214
- 267 -
42.0802220A Issue Date: 08/14
Section 10
10.03 Hydraulic Jack Assembly
