Ag-Bag LX1214 - Manual (Page 65)

Description Quantity Part No. Item
Elbow, 45° -12 MJIC x JIC Swivel 3 09.74126 1
Adapter, -12 ORB x 3/4 in. MJIC 3 09.74127 2
Elbow, 1 MJIC x Swivel 90° 1 21.00354 3
Adapter, -12 ORB x 1/2 in. MJIC 1 32.01940 4
Elbow, 3/4 in. MJIC x Swivel 90° 1 32.01941 5
Elbow, -16 ORB x -16 MJIC 1 32.02512 6
Adapter, -12 ORB x 1 in. MJIC 2 32.02639 7
Elbow, 1 in. FJIC x MJIC 45° 2 32.03090 8
Flange Elbow, 2 in. Code 61 1 32.03762 9
Flange Kit, 2 in. Code 61 1 32.03793 10
Connector, -37° Flare -ORB 7/8-14 1 40.00147 11
Pump, Hydraulic 98 cc Load Sense 1 42.0800245 12
Compensator Valve 1 42.0801170 12a
Load Sense Valve 1 42.0801171 12b
Port Plate AR 42.0801168 12c
Seal Kit AR 42.0801169 12d
Shaft Seal AR 42.0801172 12e
Pump, Hydraulic 19.2 cc Clutch (S/N 4205279 & Before) Order 42.0801308.5
for replacement 1 NLA 13
Pump: Hyd 19cc Clutch (S/N 4205280 & After) 1 42.0801308.5 13
Pump, Hydro Fan Drive 1 42.0800248.5 14
Adapter, -12 ORB x 7/8 in. MJIC 1 42.1540551 15
Pump, Hydraulic 25 cc, Beater 1 42.0800247.5 16
Washer, Lock, 1/2 in. 6 900506 17
Washer, Flat, 1/2 in. 6 901937 18
Bolt, Hex, 1/2-13 x 2 in. Gr 5 6 902050 19
Bolt, Hex, 3/8-16 x 1-1/2 in. 4 903848 20
Bolt, Hex, 5/8-11 x 2 in. Gr5 2 904253 21
Washer, Lock, 3/8 in. Stainless Steel 4 907412 22
Washer, Lock, 5/8 in. Stainless Steel 2 907419 23
Washer, Flat Wide, 3/8 in. Stainless Steel 4 907465 24
Union -04ORB -06MJIC 1 907695 25
Tee, -24 JIC Branch Swivel 1 908085 26
Reducer With Nut, 24 -16 JIC 2 908086 27
Flange Kit, SAE, 1-1/2 in. Code 62 1 908088 28
Adapter, 1-1/2 in. Code 62 x -24 MJIC 1 908089 29
Seal Kit (For Item 13 S/N 4205279 & Before) & (Item16) AR 42.0800799 30
Kit: Hyd Pump Seal (For Item 13 S/N 4205280 & After) 1 42.0801309 30
Shaft & Bearing Kit (For Item 14) AR 42.0801174 31
Swash Plate Kit (For Item 14) AR 42.0801175 32
Rotating Group Kit (For Item 14) AR 42.0801176 33
Valave Plate Kit (For Item 14) AR 42.0801177 34
LX1214 - 65 - 42.0802220A Issue Date: 08/14
Section 3
3.11 Hydraulic Pump Assembly
