Description
Quantity
Part No.
Item
Ring Gear
1
42.0801221
1
Screw
3
NSS
2
Pin
3
NSS
3
End Plate
1
NSS
4
Pad
1
NSS
5
Pad
1
NSS
6
Snap Ring
1
NSS
7
Output Plan Carrier
1
NSS
8
O Ring Seal
1
42.0801222
9
O Ring Seal
2
42.0801219
10
Planetary Gear
3
42.0801224
11
Elastic Pin
6
42.0801225
12
Needle
216
42.0801226
13
Pin
3
42.0801227
14
Spacer
6
42.0801228
15
Sun Gear
1
42.0801229
16
Snap Ring
1
NSS
17
Coupling
1
NSS
18
Input Planetary Carrier
1
NSS
19
Ring
1
NSS
20
Washer
3
NSS
21
Snap Ring
1
NSS
23
Planetary Assembly (Consists of Items 1-21)
1
42.0801434
LX1214
- 239 -
42.0802220A Issue Date: 08/14
Section 8
8.12 Gear Set RE3510 (GB16002)
