11 steering sensor assembly – Ag-Bag LX1214 User Manual
Page 39
Description
Quantity
Part No.
Item
Screw, Slotted Pan Hd. #10-32 x 3/8 in. Stainless Steel
2
907403
1
Nut, Hex, 5/16-18 Nylock Stainless Steel
4
907390
2
Bolt, Hex, 5/16-18 x 1-1/4 in. Gr 5
4
904464
3
Washer, Flat, 5/16 in.
8
904324
4
Pin, Spring, 5/32 in. x1-1/4 in.
6
904246
5
Nut, Hex Lock, 1/4-20 Nylock
6
904092
6
Bolt, Hex, 1/4-20 x 2 in. Gr 5
6
903851
7
Washer, Flat, 1/4 in. SAE Yellow Zinc
12
900493
8
Screw, Set, 3/8 in. x 1/2 in.
6
900445
9
Ring, Steering Sensor
2
42.0801059
10
Arm, Steering Sensor
2
42.0801058.5
11
Plate, Sensor Mount
2
42.0800612
12
Rotary Sensor SRS 880
2
42.0800244
13
LX1214
- 39 -
42.0802220A Issue Date: 08/14
Section 1
1.11 Steering Sensor Assembly
