Description
Quantity
Part No.
Item
Clip, Mounting DT Connector .433 Hole
1
42.0801135
3
Plug, Deutsch Cavity
19
21.22579
6
Receptacle, Deutsch DTHD04-1-4P
2
42.0801129
14
Lock, Deutsch 12 Socket Plug
1
21.22553
15
Plug, Deutsch 12 Socket
1
21.22540
16
Plug, Deutsch DTHD06-1-4S
1
42.0801130
17
Actuator, Carl RKR Red Lens
2
42.1501593
18
Pin, Deutsch Connector Size 4
2
42.1501568
19
Cord Grip, 4 Hole
1
42.0801137
21
Receptacle, Deutsch DT04-12PA-P031
1
42.0801136
24
Connector, Deutsch HDP 24-24-21 Pin
1
42.1501549
25
Nut, Cord Grip
1
42.0801138
26
Receptacle, Deutsch 23 Pin (Plastic)
1
21.22725
30
Washer, Lock, 1-11/16 in.
4
21.20126
31
Nut, 1-11/16 - 18
4
21.20127
32
Gasket, Receptacle HDP24
4
42.0801139
33
Receptacle, Deutsch, 31 Pin (Plastic)
2
21.00962
41
Plug, Deutsch HD16-4-4S
1
42.0801123
42
Strain Relief, Amp 16 Pos
1
42.0801141
43
Strain Relief, Amp 16 Comb
1
42.0801140
44
Plug, Deutsch 6 Socket
1
21.22536
45
Lock, Deutsch, 6 Socket Plug
1
21.22549
48
Connector, 16 Pin Female, Comb Amp
1
21.00981
49
Connector, 16 Pin Female Amp
1
21.00976
50
Receptacle, Deutsch HDP24-24-31SN
1
42.0801124
51
LX1214
- 249 -
42.0802220A Issue Date: 08/14
Section 9
9.04 Junction Box - Side & Rear Connectors
