The Part Description Index is an alphabetical index of all part descriptions included in this manual. The index shows what page(s) the part
is used on.
(
(2nd Line Down Along Top Of Frame).....273
(2nd Line Up Along Top Of Frame)....273, 275
(Along Frame Between Cylinders).....274
(Along Top Of Cab End Frame To
Bulkhead).....275
(Along Top Of Frame).....274
(Bag Pan From Divider Toward Engine
End).....274
(Bag Pan Lines Under Hopper To
Divider).....273
(Bag Pan Lines Under Hopper To Tee).....273
(Bag Pan Tee At Item19 Toward Engine
End).....274
(Boom Down Valve Bottom Port To Cylinder
Rod End).....202
(Boom Extend Valve Top Port To Cylinder
Base).....202
(Boom Retract Valve Bottom Port To Cylinder
Rod End).....202
(Boom Up Valve Top Port To Cylinder
Base).....202
(Bottom Line Along Top Of Frame).....273
(Bottom Valve To Item 45).....274
(Bottom Valve To Needle Valve).....274
(Cab End Frame, 2nd And 4th Down (Pair With
Item 6).....273
(Cab End Frame, 2nd And 4th Down (Pair With
Item 8).....273
(Cab End Frame, 3rd Down (Pair With Item
7).....273
(Cab End Frame, Top And 3rd Down (Pair With
Item 4).....273
(Cab End Frame, Top Tunnel Side.....273
(Cab End Jack Item 32 Tube To
Bulkhead).....275
(Cab End Jack Item 33 Tube To
Bulkhead).....275
(Cab End Lift Cylinder).....275
(Cab End Valve Bottom To End Frame) (2nd
From Top Of 4 Lines).....274
(Cab End Valve Bottom To P.O. Check).....274
(Cab End Valve Bottom To Steering Cylinder
Hose).....274
(Cab End Valve To Feed Table Hoses (2
Per).....274
(Cab End Valve Top To End Frame) (Bottom
Of 4 Lines).....274
(Cab End Valve Top To P.O. Check).....274
(Cab End Valve Top To Steering Cylinder
Hose).....273
(Divider Valve Toward Cab End).....274
(End Frame 2nd Line Down).....273
(End Frame Bottom Line).....273
(End Frame Case Drain).....273
(End Frame Engine End Park Brake).....274
(End Frame Engine End Top).....273
(Engine End Lift Cylinder).....275
(From Tees Along Top Of Frame Engine
End).....275
(P.O. Check To Tee At Item 36).....274
(P.O. Check To Tee At Item 42).....274
(Rotate In Valve Top Port To Cylinder
Base).....201
(Rotate Out Valve Bottom Port To Cylinder
Rod End).....201
(Tee At Item 19 Toward Cab End).....274
(Top Line Along Top Of Frame).....273
(Top Valve To Item 44).....274
(Top Valve To Line Body For Anchor (Runs
With Item 31).....274
(Winch Down Valve Bottom Port To Winch
Motor Top Port).....201
(Winch Up Valve Top Port To Winch Motor
Bottom Port).....201
1
1/8 in. NPT x 1/4 in. Compression Fitting...103
2
2 in. Dia Shaft - 1/2 in. Keyway.....173
7
7-Way Round Light Connector.....243
A
AC Compressor Switch.....121
AC/Heat Temperature Switch.....121
Actuator.....125
Actuator Kit.....277, 279
Actuator, Carl RKR Red Lens.....249
Actuator: Carl Rkr Red Lens.....113
Adapter.....125
Adapter - 1/2 M JIC x -16 ORB.....51, 261
Adapter - M12 x 1.5 1/4 in. FPT.....43
Adapter, -06 ORB x 1/2 M JIC.....89, 199
Adapter, -06 ORB x 3/8 in. MJIC.....201, 277
Adapter, -06 ORB x 3/8 M JIC.....55, 205, 279
Adapter, -06 ORB x 3/8 M Jic.....217
Adapter, -06 ORB x FJIC Swivel.....89
Adapter, -08 ORB x 1/2 in. MJIC.....267
Adapter, -08 ORB x 1/2 M JIC.....51, 57, 181,
189, 279
Adapter, -1/2 in. MJIC x -16 ORB.....201
Adapter, -10 ORB x 1/2 in. MJIC.....277
Adapter, -10 ORB x 1/2 M JIC...221, 269, 279
Adapter, -10 ORB x 6 MJIC, 90°.....277
Adapter, -12 MJIC x -10 ORB....171, 277, 279
Adapter, -12 Mjic x -16 Bspp.....217
Adapter, -12 ORB x 1 in. MJIC.....65
Adapter, -12 ORB x 1/2 in. MJIC.....65
Adapter, -12 ORB x 1/2 M JIC.....269
Adapter, -12 ORB x 1/2 M Jic.....217
Adapter, -12 ORB x 3/4 in. MJIC.....65
Adapter, -12 ORB x 3/4 Jic Swivel.....217
Adapter, -12 ORB x 3/4 M Jic.....217
Adapter, -12 ORB x 7/8 in. MJIC.....65
Adapter, 1 in. MPT x -08 MJIC.....265
Adapter, 1-1/2 in. Code 62 x -24 MJIC.....65
Adapter, 1/2 F JIC x 3/8 M JIC.....271
Adapter, 1/2 FJIC x 1/4 MJIC.....93
Adapter, 1/2 FJIC x 3/8 FPT.....9, 271
Adapter, 1/2 M JIC To 1/2 MPT.....11, 15, 19,
23, 89, 189, 261, 269
Adapter, 2 in. MPT x 2 in. MJIC.....261
Adapter, 3/4 F JIC To 1/2 M JIC.....11, 15, 19,
23, 51, 271
Adapter, 3/4 F Jic To 1/2 M Jic.....217
Adapter, 3/4 F Jic To 1/4 M Jic.....217
Adapter, 3/4 in. Code 61 x -12 MJIC.....55
Adapter, 3/4 MJIC x -16 ORB.....51, 261
Adapter, Black Bruin 12f4omxs.....11, 15, 19,
23
Adapter, Black Bruin 8f4omxs......11, 15, 19,
23
Adapter, Breather Filter.....261
Adapter, QJ1/4TT- NYB.....209
Adapter: -06 ORB x 1/2 MJIC.....279
Adapter: M27-3/4F8 OHGS.....43
Adaptor - 10 ORB x 6 MJIC 90d.....279
Adjuster.....147, 151
Adjuster, Slack.....11, 15, 19, 23
Adjuster- Feedtable Roller Wld.....169
Agitator, Nylon T-10 VH Complete.....209
Air Cleaner.....47
Air Conditioning Section.....51
Air Duct.....121
Air Duct, R.H......115
Air Duct. Blower.....117
Air Filter - Charcoal.....131
Air Filter, Recirculation.....117
Air Fitting, 1/4 in. MPT x 3/8 in. Tube.....103
Air Gauge, 150 Psi Back Mt.....113
Air Horn, Floater.....71, 243
Air Vent 3/8 in. NPT (Optional).....173
Aircoils: Basic Set 12 Ft.....287
Alternator: QSX.....43
Anchor Block, Feedtable Mounting Block..181
Angle, Engine Cooler (top & Bottom).....75
Angle, Engine Cooler Mount Wldmt (hinge
Side).....75
Angle, Engine Cooler Mount Wldmt (latch
Side).....75
Antenna (Cab S/N 720182 & Before).....161
Antenna (Cab S/N 720183 & After).....161
Antirotation Ring.....237
Arm.....167
Arm, Steering Sensor.....39
Armrest, Machined RH Cab.....111
Asm: 8 in. Anchor Cylinder W/o Pulleys.....269
B
Bar: Mount Backing W/nuts.....187
Barrier.....133
Base - Filter O-Ring.....217
Base Lg Curve, Belt Shield 11000.....225
Base Sm Curve, Belt Shield 11000.....225
Base Wdmt - Belt Shield 11000.....225
Battery Box Weldment.....245
Battery, 925 CCA.....245
Bearing.....27, 55, 135, 231, 233, 237, 241
Bearing - 1-3/4 Cam Follower.....81
Bearing - 2 3/16 Takeup.....169
Bearing - 2-3/16 4-Bolt Flange.....221
Bearing - 2-3/16 4-Bolt Flange, Shaved....169
Bearing Cone (Inner).....173
Bearing Cone (Outer).....173
