11
GPS 2500/2500B S
MART
A
NTENNA
O
PERATING
THE
B
AS
E
S
TA
T
IO
N
M
ENU AND
I
TEM
S
ELECTION
For many instructions in this User Guide the following example illustrates the nomenclature used for
navigating the menus.
“On the Top menu select Data Logging > Config” is the equivalent to saying “On the Top menu select
Data Logging and press Enter. Then select Config and press Enter.”
When making selections for a menu item, such as selecting Yes or No for Auto-Name (Data Logging >
Config menu), the instructions will indicate to select the menu item and press Enter to allow you to then
select an option for that menu item and then press Enter again to select that option.
Entering Alphanumeric Characters
Use the Up Arrow and Down Arrow buttons to enter alphanumeric characters (for example, when
entering a job name or a subscription code).
To enter alphanumeric characters:
1. At the prompt, press the Down Arrow button to scroll to the desired
character. The character appears on a black background when the
prompt is active.
2. Press Enter to select the character. The prompt moves to the next
character.
3. Press Enter when done.
Indicator Purpose Example
Display
indicator
Go to the indicated
submenu
This indicator also
appears to the right of the
“Back” and “Top Menu”
menu items.
• Pressing Enter when
“Back” is selected
returns you to the
previous menu.
• Pressing Enter when
“Top Menu” is selected
returns you to the Top
menu.
1. On the Top menu press the Down Arrow button
to highlight System Setup. The Display indicator
appears to the right of System Setup.
2. Press Enter to display the System Setup menu.
3. Press the Down Arrow button again to highlight
the Display Format option and then press Enter.
The items on the Display Format menu appear and
the Select indicator appears to the right of Disp
Update (the first item on the Display Format menu).
4. Press Enter on the Disp Update item. The
Display indicator changes to the Select indicator.
5. Press the Up Arrow or Down Arrow button to
scroll through the available options (such as 1Hz
and 5Hz).
6. Press Enter on the highlighted option to select it.
That option is now the setting for the menu item and
the Select indicator changes back to the Display
indicator.
Select
indicator
Scrolls within a menu to
highlight an option to
select.
Down
Arrow
button
Enter
button
