PF3000 Cotton Yield Monitor
General
Ag Leader Technology
March 2002
1-8
Emitter
Detector
Flow Sensor
Below is an example of a flow sensor. On all cotton pickers, the flow
sensor installs on the basket duct. The flow sensor measures the cotton
weight in pounds as the cotton passes between the emitter and detector.
Figure 4: Flow Sensor
