Light Bar PF Monitor Setup for Light Bar
Ag Leader Technology
7. Scroll down to Brightness and press EDIT key. (Figure 31) Use
the up or down arrow key to select the lightbar display brightness
from 1 (dimmest) to 5 (brightest) and press ACCEPT key. (Figure
32)
GPS/LIGHTBAR
Lightbar
Status OFF
Mounting Position Dash
Brightness (1-5) 5
Text Mode PASS # & ERROR
Proximity Sensitivity 25 ft
LED Spacing Mode LINEAR
LED Spacing 5.0 ft
End Distance --- ft
EDIT EXIT
Figure 31.
GPS/LIGHTBAR
Lightbar
Status ON
Mounting Position Dash
Brightness (1-5) 5
Text Mode PASS # & ERROR
Proximity Sensitivity 25 ft
LED Spacing Mode LINEAR
LED Spacing 5.0 ft
End Distance --- ft
ACCEPT CANCEL
Figure 32.
March 2001 Rev.1 3000135 33
