Reset: Resets Guidance to begin a new field. Pattern and
headland points are cleared.
Pause: Used to leave the field in mid swath. Press once to
disable guidance. Leave the swath. The system guides
back to the pause location. Press this key again to
resume swathing.
ADD/STRT: Adds a point to the headland or starts logging
headland points.
CLR/STOP: Deletes the last point entered from the headland
or stops logging headland points.
F1: HOME 40 L1: ENDS DG >
TARGET
[
auto man]
160
bu/ac
TOTAL SEEDS
300125
sds
AREA
10.1
acres
PASS NUMBER
<
left right >
A-B
Application: CORN 1 AREA ON
FIELD LOAD SHOW MAP OPTIONS
200
OPTIONS SELECTIONS
Application: CORN 1 AREA ON
MARKS LIGHTBAR NAV BoUNDARY
LIGHTBAR
Application: CORN 1 AREA ON
< SET A SET B RESET PAUSE >
RESUME
Screen Info Line
Active
Display
Menu Line
Status Line
PRESS < > TO GET ADDITIONAL SELECTIONS
Application: CORN AREA ON
< ADD/STRT CLR/STOP >
Figure 10
