Light Bar General Operation
Ag Leader Technology
Using In-Field
Guidance
The Pause/Resume feature disables lightbar guidance in mid-swath.
You can leave the swath, navigate back to the work location and resume
swathing.
By pressing the pause/resume key, you can leave the current swath.
When restarting, the lightbar provides guidance to help align the vehicle
with the swath that was active when guidance was paused. To use the
lightbar to find the active swath:
The LED illuminates green when the vehicle is within the
Approach LED sensitivity setting of the pause.
When the LED turns green, press resume to continue. See
Figure 25 for an example.
Pass Direction
Figure 25. Approach LED Sensitivity with Pause/Resume Point
***
Red
Red
Amber
Approach LED
Sensitivity
Amber
Green
Pause/Resume Point LED Sensitivity
May 2001 Rev.2 3000135 31
