Figure 8. headland approach led action for curved, Light bar, Ag leader technology – Ag Leader PFadvantage Advanced Light Bar Operators Manual User Manual
Page 15
Light Bar
General Information
Ag Leader Technology
Approach LED
Action
Figures 7 through 9 show the action of the lightbar LED for different
patterns and headland types.
RED
Figure 7. Headland Approach LED Action for AB ENDZONE
A
B
RED
GREEN
Green
Orange
Red
Red
Orange
Green
Operator sees
Approach LED
change colors near
headland boundary
Headland: Vehicle centerline on
last headland pass
Figure 8. Headland Approach LED Action for Curved
February 2003
Rev.3 3000135
11
