General Information Light Bar
Ag Leader Technology
GPS/GUIDANCE
Pattern NONE
Headland
Type CURVED
Look – Ahead 3 SEC
Display Mode SHOW CORRECTION
Swath Direction Auto
Swath Width 60.0 ft
Antenna Offset +20.0 ft
Pass Skips 2
Units Displayed English
Contour Log Interval SWATH CHANGE
EDIT EXIT
Figure 6
Explanation of
GPS/Guidance
Screen
Use Figure 6 to note the location of items on the screen.
NOTE: The Light Bar may be used in GRAIN HARVEST,
APPLICATION RATE or SITE VERIFICATION modes. Refer to
Console Setup in the Setup Section of the PF monitor Operator’s
Manual.
Pattern: Determines which guidance pattern is driven.
None: Configures straight line guidance parallel to the
beginning and end of the first swath driven.
Curve Spiral: Use this curve setting to drive spirals or
closed rings.
Curve: Activates last curve following. Positions are
logged during current swath. The next swath is
parallel to the previous swath driven.
Skip Pass: Provides parallel guidance in a racetrack pattern
with a user specified swath skip. This setting is
for equipment with a large turn radius.
A+ Heading: Allows establishing a reference line from True North
February 2003 Rev.3 3000135 8
