Light Bar General Information
Ag Leader Technology
General
Information
Use the following information to determine your requirements to setup
the PF Series monitor for your Light Bar.
NOTE: The Add-On GPS3050/3100, or GPS 4100 are the only
receivers that can operate the Ag Leader Light Bar.
GPS/LIGHTBAR
Lightbar
Status ON
Mounting Position Dash
Brightness (1-5) 5
Text Mode PASS # & ERROR
Proximity Sensitivity 25 ft
LED Spacing Mode LINEAR
LED Spacing 1.0 ft
End Distance --- ft
EDIT EXIT
Figure 4
Explanation of
GPS/Lightbar
Screen
Use Figure 4 to note the location of items on the screen.
NOTE: The Light Bar may be used in GRAIN HARVEST,
APPLICATION RATE or SITE VERIFICATION modes. Refer to
Console Setup in the Setup Section of the PF monitor Operators
Manual.
Lightbar Status: ON signifies that power is being sent to the light
bar.
Mounting Position: Ceiling mounting of the lightbar requires that it
be inverted. This setting will allow the text to be inverted also.
Brightness (1-5): This setting (1 = dim, 5 = bright) allows you to
determine the brightness of the LED on the lightbar.
February 2003 Rev.3 3000135 5
