PF Monitor Setup for Guidance Light Bar
Ag Leader Technology
8. Scroll down to Antenna Offset and press EDIT key. (Figure 56)
Use the up or down arrow key to set Antenna Offset from –100 to
+100 ft and press ACCEPT key. (Figure 57)
NOTE: Antenna Offset could be a negative number if your spray
boom is mounted in front of the antenna. Positive numbers indicate
a boom mounted behind the antenna.
GPS/GUIDANCE
Pattern NONE
Headland
Type CURVED
Look – Ahead 3 SEC
Display Mode SHOW CORRECTION
Swath Direction Auto
Swath Width 60.0 ft
Antenna Offset 20.0 ft
Pass Skips 15
Units Displayed English
Contour Log Interval HEADING CHANGE
EDIT EXIT
Figure 56.
GPS/GUIDANCE
Pattern CURVE
Headland
Type CURVED
Look – Ahead 3 SEC
Display Mode SHOW CORRECTION
Swath Direction Auto
Swath Width 60.0 ft
Antenna Offset 20.0 ft
Pass Skips 15
Units Displayed English
Contour Log Interval HEADING CHANGE
ACCEPT CANCEL
Figure 57.
March 2001 Rev.1 3000135 46
