Light Bar PF Monitor Setup for Guidance
Ag Leader Technology
5. Scroll down to Display Mode and press EDIT key. (Figure 50)
Use the up or down arrow key to select “Show Correction” or
“Show Error” and press ACCEPT key. (Figure 51)
GPS/GUIDANCE
Pattern NONE
Headland
Type CURVED
Look – Ahead 3 SEC
Display Mode SHOW CORRECTION
Swath Direction Auto
Swath Width 60.0 ft
Antenna Offset 20.0 ft
Pass Skips 15
Units Displayed English
Contour Log Interval HEADING CHANGE
EDIT EXIT
Figure 50.
GPS/GUIDANCE
Pattern CURVE
Headland
Type CURVED
Look – Ahead 3 SEC
Display Mode SHOW CORRECTION
Swath Direction Auto
Swath Width 60.0 ft
Antenna Offset 20.0 ft
Pass Skips 15
Units Displayed English
Contour Log Interval HEADING CHANGE
ACCEPT CANCEL
Figure 51.
March 2001 Rev.1 3000135 43
