PF Monitor Setup for Light Bar Light Bar
Ag Leader Technology
12. Scroll down to End Distance and press EDIT key. (Figure 41) If
SCALED is used, the first 10 LED’s are normal spacing and the
remaining LED distance represents the difference to the end
distance. Enter that value and press ACCEPT key. (Figure 42)
GPS/LIGHTBAR
Lightbar
Status OFF
Mounting Position Dash
Brightness (1-5) 5
Text Mode PASS # & ERROR
Proximity Sensitivity 25 ft
LED Spacing Mode LINEAR
LED Spacing 5.0 ft
End Distance --- ft
EDIT EXIT
Figure 41.
GPS/LIGHTBAR
Lightbar
Status ON
Mounting Position Dash
Brightness (1-5) 5
Text Mode PASS # & ERROR
Proximity Sensitivity 25 ft
LED Spacing Mode LINEAR
LED Spacing 5.0 ft
End Distance --- ft
ACCEPT CANCEL
Figure 42.
13. Press EXIT key to return to GPS Setup screen.
***
March 2001 Rev.1 3000135 38
