Light Bar PF Monitor Setup for Light Bar
Ag Leader Technology
11. Scroll down to LED Spacing and press EDIT key. (Figure 39) Use
the up or down arrow keys to select a setting from 0.1 to 9.9 ft and
press ACCEPT key. (Figure 40)
GPS/LIGHTBAR
Lightbar
Status OFF
Mounting Position Dash
Brightness (1-5) 5
Text Mode PASS # & ERROR
Proximity Sensitivity 25 ft
LED Spacing Mode LINEAR
LED Spacing 5.0 ft
End Distance --- ft
EDIT EXIT
Figure 39.
GPS/LIGHTBAR
Lightbar
Status ON
Mounting Position Dash
Brightness (1-5) 5
Text Mode PASS # & ERROR
Proximity Sensitivity 25 ft
LED Spacing Mode LINEAR
LED Spacing 5.0 ft
End Distance --- ft
ACCEPT CANCEL
Figure 40.
March 2001 Rev.1 3000135 37
