Data Saved in the File
CSV File
ZIP File
•
Usage rates for access paths between channel
adapters and the shared memory in short
range
•
Usage rates for access paths between disk
adapters and the shared memory in short
range
PHY_Short_MPA_SMA.csv
Usage rates for access paths between cache
switches and cache memories in long range
PHY_Long_CSW_CMA.csv
Usage rates for access paths between cache
switches and cache memories in short range
PHY_Short_CSW_CMA.csv
Write pending rates in long range
PHY_Long_Write_Pending_Rate.csv
Write pending rates in short range
PHY_Short_Write_Pending_Rate.csv
Usage rates for cache memory
PHY_Short_Cache_Usage_Rate.csv
NOTE:
•
The letters
x-y in CSV filenames indicate a parity group or external volume group.
•
Both long range and short range statistics are stored about resource usage and write pending rates
Table 9 Files with Statistics about Parity Groups, External Volume Groups or V-VOL Groups
Data Saved in the File
CSV File
ZIP File
The number of read and write operations per second
PG_IOPS.csv
PG_dat.ZIP
The size of data transferred per second (The unit is KB/sec)
PG_TransRate.csv
The number of read operations per second
PG_Read_IOPS.csv
The number of sequential read operations per second
PG_Seq_Read_IOPS.csv
The number of random read operations per second
PG_Rnd_Read_IOPS.csv
The number of read operations in cache-fast-write mode per
second
PG_CFW_Read_IOPS.csv
The number of write operations per second
PG_Write_IOPS.csv
The number of sequential write operations per second
PG_Seq_Write_IOPS.csv
The number of random write operations per second
PG_Rnd_Write_IOPS.csv
The number of write operations in cache-fast-write mode per
second
PG_CFW_Write_IOPS.csv
The read hit ratio
PG_Read_Hit.csv
