Figure 79 Display Filter Window
The Display Filter window displays the following settings:
•
Host Group: Allows you to select the host group to be displayed.
If you select ALL, all host groups will be displayed in the list.
•
JNL Group: Allows you to select the journal group to be displayed.
If you select ALL, all journal groups will be displayed in the list.
•
Mirror: Allows you to select the mirror to be displayed.
If you select ALL, all mirrors will be displayed in the list.
•
P-VOL/S-VOL: Allows you to select the type of volumes to be displayed.
If you select P-VOL, primary data volumes will be displayed in the list.
If you select S-VOL, secondary data volumes will be displayed in the list.
If you select ALL, all primary data volumes and all secondary data volumes will be displayed
in the list.
•
CLPR: Allows you to select the CLPR to be displayed.
If you select ALL, all CLPRs will be displayed in the list.
•
Internal/External VOL: Allows you to specify whether internal volumes or external volumes
will be displayed in the list.
If you select ALL, all the internal and external volumes will be displayed in the list.
•
Status: Allows you to specify pair statuses. The volumes of the specified statuses will be
displayed in the list.
•
Sub Status: Allows you to specify the consistency status.
The volume pairs in the specified status will be displayed in the list.
For detailed information about the consistency status, see “Suspend Types” (page 40) and
“Consistency Status for Suspended Universal Replicator for Mainframe Secondary Data
Volumes” (page 42)
.
•
SEQCHK Only: Allows you to specify whether to display only the volume pairs in SEQCHK
status.
If this check box is selected, volumes in Simplex status will not be displayed in the list.
