Installation and Maintenance 3-11
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: RAID Array 3000 Controller Shelf Hardware User’s Guide Comments:
Part Number: EK-SMCPQ-UG. D01 File Name: d-ch3 Installation and Maintenance.doc Last Saved On: 12/4/00 1:08 PM
Table 3-3
UPS Rack-mount Bracket Mounting Hardware List
Cabinet Style Hardware Item Part Number
RETMA (round hole) Screw 90-00063-39
U-Nut 90-07786-00
RETMA (square hole) Screw 90-40331-01
Cage Nut 90-11476-01
Washer 90-06664-00
Figure 3-6 shows the left and right-hand UPS bracket assemblies. Figures 3-7
and 3-8 illustrate the front and rear bracket-mounting holes for both cabinet
designs. Refer to these figures throughout the bracket installation procedure.
1. Determine the mounting location in your cabinet (bottom of cabinet
recommended for stability).
2. Install U-nuts (or cage nuts depending on cabinet style) corresponding
to the E holes for RETMA cabinets or M holes for metric cabinets
(see Figure 3-7).
