1-24 RAID Array 3000 Controller Shelf Hardware User’s Guide
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: RAID Array 3000 Controller Shelf Hardware User’s Guide Comments:
Part Number: EK-SMCPQ-UG. D01 File Name: b-ch1 Product Overview.doc Last Saved On: 12/4/00 1:09 PM
Table 1-7
Controller Shelf Power and Physical Specifications
Operating Environment Specification
Power required 110-120/220-240 VAC, 50/60 Hz, single phase,
two 180 Watt power modules @ 2.5 / 1.2 A each
Temperature— optimal,
Temperature— minimum required
65° F to 75° F (18° C to 24° C)
50° F to 104° F) (10° C to 40° C)
Relative humidity – optimal
Relative humidity – minimum required
40% to 60% non condensing
10% to 90% non condensing
Maximum wet bulb temperature 82
o F (28 o C)
Minimum dew point: 36 o F (2 o C)
Altitude Up to 8,000 ft (2,400 m)
Inlet air volume 0.026 cubic meter per second
(50 cubic feet per minute)
Air quality Not to exceed 500,000 particles per cubic foot of air
at a size of 0.5 micron or larger
Temperature -40° F to 151° F (-40° C to +66° C)
Relative humidity 8% to 95% non condensing in original shipping
container
Altitude From – 300 m to 3,600 m (-1,000 ft. to 12,000 ft )
Physical characteristics* Installed dimensions
Controller and disk
shelves UPS
*Disk SBBs are not included.
continued
