3-8 RAID Array 3000 Controller Shelf Hardware User’s Guide
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: RAID Array 3000 Controller Shelf Hardware User’s Guide Comments:
Part Number: EK-SMCPQ-UG. D01 File Name: d-ch3 Installation and Maintenance.doc Last Saved On: 12/4/00 1:08 PM
Installing Shelf Supports in a RETMA Cabinet
(Round Hole)
Use the following procedure to install the shelf support kit into a RETMA
cabinet with round holes in the mounting rails (see Figure 3-5).
1. Open the kit and ensure it contains the items listed in Table 3-2.
Table 3-2
RETMA Cabinet Shelf Support Parts List
Item # Part Number Description Qty.
å
74-46419-01 Shelf retainer bracket, (0.25 in.) 4

74-46419-02 Shelf retainer bracket, (1.50 in.) 2
ê
74-48220-01 Shelf support – BA350-SA 1
‚
74-48220-02 Shelf support – BA350-SA 1
ƒ
74-48223-01 Nut plate 2
ñ
74-50250-01 Support bracket – BA350-24/U 1
ò
90-00063-37 Screw – 10 x 32 14
ô
90-06565-00 Nut – 10 x 32 2
2. Determine the mounting location in your cabinet.
3. Install the left shelf support by aligning the bracket and cabinet rail
holes and then securing the support to the cabinet using two screws
(item 7, Figure 3-5). Do not tighten screws.
4. Install the nut plate (item 5, Figure 3-5) behind the left rail and secure
with three screws. Tighten all five screws.
5. Repeat steps 2, 3, and 4 to install the right shelf support in the cabinet.
6. Install the support bracket (item 6, Figure 3-5) by securing the bracket
studs with two plate nuts (item 8, Figure 3-5).
7. Install a shelf retainer bracket (item 1, Figure 3-5) in the rear slot of the
left shelf support and secure with two screws.
8. Repeat step 7 to secure a shelf retainer bracket to the right shelf support.
9. Place the controller shelf on the cabinet shelf supports and slide the
shelf completely to the rear of the cabinet.
