Installation and Maintenance 3-7
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: RAID Array 3000 Controller Shelf Hardware User’s Guide Comments:
Part Number: EK-SMCPQ-UG. D01 File Name: d-ch3 Installation and Maintenance.doc Last Saved On: 12/4/00 1:08 PM
Installing Shelf Supports
After you determine the desired shelf slot locations in your cabinet, install the
shelf support mounting kits supplied with the shelves. Shelf support mounting
kits for the RETMA and metric style cabinets are included with each shelf
assembly. The UPS is rack mounted using custom adjustable rail brackets.
Table 3–1 lists the shelf support mounting kits and identifies the documents
and procedures that contain the instructions needed to install them.
Table 3-1
Shelf Support Mounting Kits and Installation Guides
Cabinet Style Shelf Support Kit
Part No.
Installation Guide/Part No.
RETMA cabinet installation
(round hole). 70-33381-01 See “ Installing Shelf Supports in a
RETMA Cabinet (Round Hole) ”
RETMA cabinet installation
(square hole). 70-33381-01 See “ Installing Shelf Supports in a
RETMA Cabinet (Square Hole) ”
Metric cabinet
Installation BA35X-RD SW500 and SW800 Cabinet Metric
Shelf Bracket Kit Installation Guide
UPS installation into a
RETMA or metric
cabinet 74-53154-01/02
(plus hardware)
See “ Installing UPS Brackets ”
