4-4 RAID Array 3000 Controller Shelf Hardware User’s Guide
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: RAID Array 3000 Controller Shelf Hardware User’s Guide Comments:
Part Number: EK-SMCPQ-UG. D01 File Name: e-ch4 Second Controller Option.doc Last Saved On: 12/4/00 1:08 PM
A Save Configuration dialog box appears as shown in Figure 4-2. The
example in Figure 4-2 shows the Save to File name as
c:\config1 .
1. Type your file name and click Save.
Figure 4-2. Save Configuration dialog box
Updating Firmware
CAUTION: If the systems disk is on the RA3000, firmware cannot be upgraded
with SWCC. Establish a temporary system disk on a disk drive outside the
RA3000 and proceed with these instructions or follow the alternative shown in
“ Updating Firmware Using Serial Interface” .
Updating Firmware Using SWCC
Start SWCC and choose SCSI or Network Connection. From the Storage
menu, click Controller, and then click Update Firmware (see Figure 4-3).
Figure 4-3. Update firmware command
