the system can chart only those elements that are specified. After you create a group in the Groups screen,
the new group automatically appears in the Array/Group drop-down menu in the Charts screen. Use the
Metric Category and Metric drop-down menus to select the metrics that you want to chart for your group.
NOTE:
The following metrics can be added only when an array is selected in the Array/Group drop-down box:
• SM CHIP Bus/FBus Hi Util
• SM ACP Bus/FBus Lo Util
• CM CHIP Bus/MBus Hi Util
• CM ACP Bus/MBus Lo Util
• Cache Usage
• Cache Write Pending Usage
• Cache Sidefile Usage
NOTE:
You will not be able to view a chart for a custom group which includes External Raid Groups (Ext-RdGp),
XP Thin Provisioning (THP), Snapshot, or Continuous Access Journal (Jrnl Grp) components.
NOTE:
Utilization Metric displays Snapshot Pool Occupancy only for XP24000.
Metric Category and Metric drop-down menus
Metric Category and Metric drop-down menus lists the fields that are available in the Metric Category
and Metric drop-down menus.
Table 28 Metric Categories and Metric Values
Metric Category Metric Description
LDEV Total IO
LDEV Total Random IO
LDEV Random Reads
LDEV Random Read
Cache Hits LDEV
Random Writes
LDEV Total Sequential IO
LDEV Sequential Reads
LDEV Sequential Read Cache Hits
LDEV Sequential Writes
LDEV Search/Read Basic Mode
LDEV Search/Read
Hits Basic Mode
LDEV Search/Read
Seq Access Mode
LDEV Search/Read
Hits Seq Basic Mode
LDEV Write Basic Mode LDEV
Write Seq Access Mode
Single LDEV.
IO Metrics
Maximum Port IO
Minimum Port IO
Average Port IO
Single port.
