19 - 33
Source dtSourceState 0 —Source is not running
1 —Source is running without the replication driver
2 —Source is running with the replication driver.
Target dtTargetState 0 —Target is not running
1 —Target is running
dtRetryCount The number of file operations that have been retried
dtOpsDroppedCount The number of file operations that have failed and will not be retried
Security dtLoginCount The number of successful logins
dtFailedLoginCount The number of unsuccessful logins
Connection dtConnectionCount The number of active connections between machines
dtconIpAddress The IP address of the connected machine. If at the source, then the IP address
of the target. If at the target, then the IP address of the source.
dtconConnectTime The duration of time since the connection was first established
dtconState The state of the active connection
0 —None. This indicates a connection has not been established. Statistics are
still available for the source and target machines.
1 —Active. This indicates that the connection is functioning normally and has
no scheduling restrictions imposed on it at this time. (There may be
restrictions, but it is currently in a state that allows it to transmit.)
2 —Paused. This indicates a connection that has been paused.
4 —Scheduled. This indicates a connection that is not currently transmitting
due to scheduling restrictions (bandwidth limitations, time frame limitations,
and so on).
8 —Error. This indicates a connection that is not transmitting because
something has gone wrong (for example, lost connection).
Only the Scheduled and Error states can coexist. All other states are mutually
exclusive. SNMP will display a dtconState of 12 when the connection is in both
a scheduled and an error state because this is the sum of the two values (4 +
8).
dtconOpsInCmdQueue The number of operations (create, modify, or delete) in the retransmit queue
on the source
dtconOpsInAckQueue The number of operations (create, modify, or delete) waiting for verification
acknowledgements from the target
dtconOpsInRepQueue The number of replication operations (create, modify, or delete) in the queue
dtconOpsInMirQueue The number of mirror operations (create, modify, or delete) in the queue
dtconBytesInRepQueue The number of bytes in the replication queue
dtconBytesInMirQueue The number of bytes in the mirror queue
dtconOpsTx The total number of operations (create, modify, or delete) transmitted to the
target
dtconBytesTx The total number of bytes transmitted to the target
dtconBytesCompressed
Tx The total number of compressed bytes transmitted to the target
dtconOpsRx The total number of operations (create, modify, or delete) received from the
target
Object Type Statistic Description
