1
2 3
Figure 41 Power supply/blower status indicator
1. Status indicator 2. Power supply/blower 1
3. Power supply/blower 2
Removing a blower
It is not necessary to remove the power supply to replace a failed blower.
WARNING!
The blower motor does not stop immediately when the blower is removed. Keep your fingers away from
the blower blades until the motor stops.
• While pushing in on the two wine-colored mounting tabs (1, Figure 42 ), pull the blower (2)
away from the power supply.
Figure 42 Removing a blower
Installing a blower
CAUTION:
Pressing on the center section of the blower can damage the blades or the housing. Only press on
the outer edge of the blower when installing it.
1. Align the blower guide post (2, Figure 43 ) with the mounting hole next to the power supply
connector (1).
2. Slide the blower onto the power supply (4) until the mounting tabs (3) snap into place.
HP StorageWorks 3000/5000 Enterprise Virtual Array user guide (VCS 4.xxx) 97
