Fibre Channel switch specifications
The Fibre Channel Switch requires a clean, dry environment for normal operation. Table 35 lists the
specifications for the Fibre Channel Switch.
Table 35 Fibre Channel switch specifications
Specification Description
Weight Approximately 7.0 lbs.
Dimensions 8.50 x 1.57 x 16.00 inches (W x H x D) NOTE: The switch with extender
is 21.66 in (depth).
Operating Temperature 0 °C to 40 °C for normal operation (ambient air temperature)
Storage Temperature -40 °C to 80 °C noncondensing
Power 50 or 60 Hz 100–250 VAC 0.6–0.4 A
Controller specifications
This section defines the physical, power, and environmental specifications of the controller enclosure.
Physical specifications
Table 36 defines the dimensions of the controller.
Table 36 Controller enclosure physical specifications
Specification Installed Shipping
Height 62 mm (2.45 in) 267 mm (10.5 in)
Width 502 mm (19.56 in) 762 mm (30 in)
Depth 444 mm (17.49 in) 762 mm (30 in)
Weight 10.4 kg (23 lb) 12.7 kg (28 lb)
Power specifications
Table 37 and Table 38 define the controller power supply input power requirements and output power
specifications.
Table 37 Controller power supply AC power requirements
AC Input Voltage Frequency
Minimum Nominal Maximum Maximum Minimum
180 VAC 202 VAC 220 VAC 47 Hz 50 Hz
208 VAC 57 Hz 60 Hz
208 VAC 240 VAC 254 VAC
