Table 38 Controller power supply output specifications
Voltage Specification Minimum Nominal Maximum
+3.3 VDC
Output Voltage Steady state current
Power
3.23 VDC 3.30 VDC 3.36 VDC 18 A
59.4W
+5.1 VDC
Output Voltage Steady state current
Power
4.80 VDC 5.00 VDC 5.25 VDC 5.0 A
25.5 W
Total Current Total Power 24 A 105.6 W
1. +3.3 VDC steady state current requires a minimum 5.0-V load of 1 A.
2. Total power includes 14.0 watts for the internal blower.
Table 39 defines the AC input current and wattage to the controller power supplies.
Table 39 AC input current and wattage
Nominal Maximum
Input Voltage Amps Watts Amps Watts
60-Hz input
100 VAC 0.928 94 1.53 150
120 VAC 0.788 94 1.25 148
208 VAC 0.576 97 0.73 146
50–Hz Input
220 VAC 0.616 102 0.69 146
240 VAC 0.573 100 0.64 147
Environmental specifications
There are no controller environmental specifications. See Environmental specifications for this information.
Rack specifications
Physical specifications
WARNING!
The weight of the drive enclosure with the elements installed always requires at least two individuals to
move. HP recommends using a fork lift or a hand truck to move an enclosure in the shipping container.
Table 40 through Table 45 define the dimensions and weights of the 9000-Series and 10000-Series
Enterprise Virtual Array racks.
