2. In the tree, select a host group.
3. From the CU drop-down list above the LDEV list, select a CU number.
The LDEV list displays LDEVs in the specified CU image.
4. Select a logical volume from the LDEV list. Next, from the LU Path list, select LUNs indicated
by the icon (this icon indicates a LUN to which no LU path is defined). Next, click the Add
LU Path button.
A message appears displaying information about LU paths to be defined ( Figure 22 on page 42).
Notes :
• If you are using Windows, you can drag a logical volume from the LDEV list to a LUN ( ) in
the LU Path list. To drag more than one logical volume, see the HP StorageWorks XP24000
Remote Web Console User's Guide.
• When you use the LU Path list, you can use the CU drop-down list to switch between CU
images.
5. Click OK to close the message.
The settings are reflected in the LU Path list, but not applied to the storage system yet.
6. Click Apply in the LUN Manager window.
A message appears and asks if you want to apply the setting to the storage system.
7. Click the OK button to close the message.
The settings are applied to the storage system and the LU paths are defined.
Figure 22 Information about LU Paths to be Defined (in Fibre Channel Environment)
Setting Fibre Channel Authentication
When configuring a Fibre Channel environment, you can use the Authentication window
( Figure 12 on page 29 and Figure 14 on page 31) to set the user authentication on host groups, Fibre
Channel ports, and Fibre Channel switches of the storage system.
This section describes the following operations on host groups, Fibre Channel ports, and Fibre Channel
switches for user authentication:
• Settings and the connection results in authentication of hosts (see
“ Host and Host Group Authentication ” on page 44)
• Settings and the connection results in authentication of Fibre Channel switches (see
“ Switch Authentication ” on page 47)
• Specifying whether to enable or disable the authentication of hosts in a host group (see
“ Enabling or Disabling Host Authentication ” on page 49)
• Registering user information for hosts on a host group (see
“ Registering Host User Information ” on page 50)
• Changing user information for hosts (see “ Changing Host User Information ” on page 51)
42 Performing LUN Manager Operations
