The setting is applied to the storage system.
Note : After you click the Option button, the dialog box expands to display the list of host mode options.
The No. column indicates option numbers. Select a check box of an option you want to specify.
Figure 19 The Add New Host Group Dialog Box
Table 2 Host Modes for Host Groups
Host mode When to select this mode
00 Standard When registering Red Hat Linux server hosts or IRIX server hosts in the host group
01 VMware
When registering VMware server hosts in the host group (see Notes below
this table)
03 HP When registering HP-UX server hosts in the host group
05 OpenVMS When registering OpenVMS server hosts in the host group
07 Tru64 When registering Tru64 server hosts in the host group
09 Solaris When registering Solaris server hosts in the host group
0A NetWare When registering NetWare server hosts in the host group
0C Windows
When registering Windows server hosts in the host group (see Notes below
this table)
0F AIX When registering AIX server hosts in the host group
21 VMware Extension
When registering VMware server hosts in the host group (see Notes below
this table)
2C Windows Extension When registering Windows server hosts in the host group (see
Notes below
this table)
4C External Storage
When registering another storage system in the host group for mapping by
using External Storage
(Use this mode when you want to map logical volumes in the storage system on
which LUN Manager is installed, to another storage system on which External
Storage is installed as the data is succeeded with the same emulation type.)
Notes:
• If you register Windows server hosts in a host group, you need to ensure that the host mode of
the host group is 0C Windows or 2C Windows Extension. If you are thinking about creating
LUSE volumes (that is, expanded LUs), you should consider setting the host mode 2C Windows
Extension to the host group.
