Port
serial
number
Standard
mode
High Speed
mode or
Initiator/External
MIX mode
Port
serial
number
Standard
mode
High Speed
mode or
Initiator/External
MIX mode
64 CL9-A CL9-A 96 CL9-J CL9-J
65 CLB-A CLB-A [9-A 2nd] 97 CLB-J CLB-J [9-J 2nd]
66 CLD-A CLD-A 98 CLD-J CLD-J
67 CLF-A CLF-A [D-A 2nd] 99 CLF-J CLF-J [D-J 2nd]
68 CL9-B CL9-B 100 CL9-K CL9-K
69 CLB-B CLB-B [9-B 2nd] 101 CLB-K CLB-K [9-K 2nd]
70 CLD-B CLD-B 102 CLD-K CLD-K
71 CLF-B CLF-B [D-B 2nd] 103 CLF-K CLF-K [D-K 2nd]
72 CL9-E CL9-E 104 CL9-N CL9-N
73 CLB-E CLB-E [9-E 2nd] 105 CLB-N CLB-N [9-N 2nd]
74 CLD-E CLD-E 106 CLD-N CLD-N
75 CLF-E CLF-E [D-E 2nd] 107 CLF-N CLF-N [D-N 2nd]
76 CL9-F CL9-F 108 CL9-P CL9-P
77 CLB-F CLB-F [9-F 2nd] 109 CLB-P CLB-P [9-P 2nd]
78 CLD-F CLD-F 110 CLD-P CLD-P
79 CLF-F CLF-F [D-F 2nd] 111 CLF-P CLF-P [D-P 2nd]
80 CL9-C CL9-C 112 CL9-L CL9-L
81 CLB-C CLB-C [9-C 2nd] 113 - CLB L CLB-L [9-L 2nd]
82 CLD-C CLD-C 114 CLD-L CLD-L
83 CLF-C CLF-C [D-C 2nd] 115 CLF-L CLF-L [D-L 2nd]
84 CL9-D CL9-D 116 CL9-M CL9-M
85 CLB-D CLB-D [9-D 2nd] 117 CLB-M CLB-M [9-M 2nd]
86 CLD-D CLD-D 118 CLD-M CLD-M
87 CLF-D CLF-D [D-D 2nd] 119 - CLF M CLF-M [D-M 2nd]
88 CL9-G CL9-G 120 CL9-Q CL9-Q
89 CLB-G CLB-G [9-G 2nd] 121 CLB-Q CLB-Q [9-Q 2nd]
90 CLD-G CLD-G 122 CLD-Q CLD-Q
91 CLF-G CLF-G [D-G 2nd] 123 CLF-Q CLF-Q [D-Q 2nd]
92 CL9-H CL9-H 124 CL9-R CL9-R
93 CLB-H CLB-H [9-H 2nd] 125 CLB-R CLB-R [9-R 2nd]
94 CLD-H CLD-H 126 CLD-R CLD-R
95 CLF-H CLF-H [D-H 2nd] 127 CLF-R CLF-R [D-R 2nd]
Note: The hyphen (-) indicates that the port is not available.
Performing LUN Manager Operations 74
