Table 14 Available Configuration Values for the [HostGroup] Tag
Column Item Available Values
1st, 11th
(Index)
Port
One of the following can be set (Maximum number of ports is 256):
1A, 1B, 1C, 1D, 1E, 1F, 1G, 1H, 1J, 1K, 1L, 1M, 1N, 1P, 1Q, 1R,
2A, 2B, 2C, 2D, 2E, 2F, 2G, 2H, 2J, 2K, 2L, 2M, 2N, 2P, 2Q, 2R,
3A, 3B, 3C, 3D, 3E, 3F, 3G, 3H, 3J, 3K, 3L, 3M, 3N, 3P, 3Q, 3R,
4A, 4B, 4C, 4D, 4E, 4F, 4G, 4H, 4J, 4K, 4L, 4M, 4N, 4P, 4Q, 4R,
5A, 5B, 5C, 5D, 5E, 5F, 5G, 5H, 5J, 5K, 5L, 5M, 5N, 5P, 5Q, 5R,
6A, 6B, 6C, 6D, 6E, 6F, 6G, 6H, 6J, 6K, 6L, 6M, 6N, 6P, 6Q, 6R,
7A, 7B, 7C, 7D, 7E, 7F, 7G, 7H, 7J, 7K, 7L, 7M, 7N, 7P, 7Q, 7R,
8A, 8B, 8C, 8D, 8E, 8F, 8G, 8H, 8J, 8K, 8L, 8M, 8N, 8P, 8Q, 8R,
9A, 9B, 9C, 9D, 9E, 9F, 9G, 9H, 9J, 9K, 9L, 9M, 9N, 9P, 9Q, 9R,
AA, AB, AC, AD, AE, AF, AG, AH, AJ, AK, AL, AM, AN, AP, AQ, AR,
BA, BB, BC, BD, BE, BF, BG, BH, BJ, BK, BL, BM, BN, BP, BQ, BR,
CA, CB, CC, CD, CE, CF, CG, CH, CJ, CK, CL, CM, CN, CP, CQ, CR,
DA, DB, DC, DD, DE, DF, DG, DH, DJ, DK, DL, DM, DN, DP, DQ, DR,
EA, EB, EC, ED, EE, EF, EG, EH, EJ, EK, EL, EM, EN, EP, EQ, ER,
FA, FB, FC, FD, FE, FF, FG, FH, FJ, FK, FL, FM, FN, FP, FQ, FR,
GA, GB, GC, GD, GE, GF, GG, GH, GJ, GK, GL, GM, GN, GP, GQ, GR
2nd, 12th
(Index)
Group Id 00 - FE. Set with hexadecimal numbers in one or two digits.
3rd, 13th Group Name
Up to 32 ASCII characters (letters, numerals, and symbols). The setting
is case-sensitive.
4th, 14th Host Mode 00 - 4F. Set with hexadecimal numbers in one or two digits.
5th, 15th Option[0:31] 0 - FFFFFFFF. Set with hexadecimal numbers in from one digit to eight
digits*.
The default value when the spreadsheet is exported is in eight digits.
0s at the head of the number can be omitted when you set the value.
6th, 16th Option[32:63]
7th, 17th Option[64:95]
Note*: Figure 46 on page 95 shows the concept of the host mode option. The host mode option
consists of 96 flags, which are from 0 to 95. The host mode option is stored by dividing 32 flags.
Figure 46 on page 95 illustrates these flags as the option flag ID from 0 to 31. The binary bit flags (option
flags) are given to each ID (starting with 0), and every four binary bit flags are set as a group to be
converted to the hexadecimal number that finally represents the host mode option. Figure 47 on page 95
show an example of the host mode option. In the case of Figure 47 on page 95, the host mode option
becomes 1AB30005.
For the binary to the hexadecimal conversion, see
Table 15 on page 95.
The host mode option should be written in one digit or more (up to eight digits). 0s at the head of the
number can be omitted when you set the value. For example, 00000FE3 can be written as FE3. The
default value when the spreadsheet is exported is written in eight digits.
