Table 13 Available [Port] Tag Configuration Values
Column Item Available Value
1st, 11th
(Index)
Port
Set one of the following (Maximum number of ports is 256):
1A, 1B, 1C, 1D, 1E, 1F, 1G, 1H, 1J, 1K, 1L, 1M, 1N, 1P, 1Q, 1R,
2A, 2B, 2C, 2D, 2E, 2F, 2G, 2H, 2J, 2K, 2L, 2M, 2N, 2P, 2Q, 2R,
3A, 3B, 3C, 3D, 3E, 3F, 3G, 3H, 3J, 3K, 3L, 3M, 3N, 3P, 3Q, 3R,
4A, 4B, 4C, 4D, 4E, 4F, 4G, 4H, 4J, 4K, 4L, 4M, 4N, 4P, 4Q, 4R,
5A, 5B, 5C, 5D, 5E, 5F, 5G, 5H, 5J, 5K, 5L, 5M, 5N, 5P, 5Q, 5R,
6A, 6B, 6C, 6D, 6E, 6F, 6G, 6H, 6J, 6K, 6L, 6M, 6N, 6P, 6Q, 6R,
7A, 7B, 7C, 7D, 7E, 7F, 7G, 7H, 7J, 7K, 7L, 7M, 7N, 7P, 7Q, 7R,
8A, 8B, 8C, 8D, 8E, 8F, 8G, 8H, 8J, 8K, 8L, 8M, 8N, 8P, 8Q, 8R,
9A, 9B, 9C, 9D, 9E, 9F, 9G, 9H, 9J, 9K, 9L, 9M, 9N, 9P, 9Q, 9R,
AA, AB, AC, AD, AE, AF, AG, AH, AJ, AK, AL, AM, AN, AP, AQ, AR,
BA, BB, BC, BD, BE, BF, BG, BH, BJ, BK, BL, BM, BN, BP, BQ, BR,
CA, CB, CC, CD, CE, CF, CG, CH, CJ, CK, CL, CM, CN, CP, CQ, CR,
DA, DB, DC, DD, DE, DF, DG, DH, DJ, DK, DL, DM, DN, DP, DQ, DR,
EA, EB, EC, ED, EE, EF, EG, EH, EJ, EK, EL, EM, EN, EP, EQ, ER,
FA, FB, FC, FD, FE, FF, FG, FH, FJ, FK, FL, FM, FN, FP, FQ, FR,
GA, GB, GC, GD, GE, GF, GG, GH, GJ, GK, GL, GM, GN, GP, GQ, GR
2nd, 12th
Security
Switch (LUN
Security)
Enable or Disable (The default when the spreadsheet is exported)
ON or OFF are also available as the set value when you write the
spreadsheet.
3rd, 13th AL-PA Set with hexadecimal numbers in one or two digits.
4th, 14th Fabric
Enable or Disable (The default when the spreadsheet is exported)
ON or OFF are also available as the set value when you write the
spreadsheet.
5th, 15th Connection FC-AL or PtoP
6th, 16th
Channel
Speed
Set one of the following:
1, 2, 4, or Auto
Setting the Host Group
The [HostGroup] tag allows you to add, delete, or change the host group information. The following
parameters apply:
• You can delete the settings for host group 0 (zero), but the host group itself cannot be deleted. If
you delete all the settings for host group 0, the settings revert to the default settings.
• When you delete a host group, the WWN and path definition of that host group are automatically
deleted. Therefore, if you write the settings for a host group that is deleted in the [LUN] tag or
[WWN] tag, an error occurs.
Table 14 on page 94 lists the items and values available for the [HostGroup] tag.
XP24000 LUN Manager User's Guide 93
