CLX-Y
Indicates a Fibre Channel port.
host group name
Indicates that the host group performs authentication of hosts.
Indicates that the host group does not perform authentication
host group name of hosts.
Authentication Information (Target) List
The Authentication Information (Target) list displays user information for host groups that are allowed to
connect to the port or host groups specified in the tree.
Group Name Indicates names of the host groups.
User Name
Indicates the user name of the host group. When the user name is not
defined for a host group, this column becomes blank.
Indicates whether to perform authentication for the host. If the host is a
Authentication target of user authentication, Enable appears. If the host is not a target
of user authentication, Disable appears.
Authentication Information (Host) List
The Authentication Information (Host) list displays user information for the port or host group selected
in the tree.
In this list, you can register up to 64 user information items.
Group Name Indicates names of host groups.
User Name
Indicates user names of hosts. When the user name is not defined for a
host, this column becomes blank.
Protocol Indicates the protocol used in the user authentication.
• Apply
Applies settings in the window to the storage system.
• Cancel
Cancels settings in the window.
32 Using the LUN Manager GUI
