Switch Admin Window
96 Web Tools Version 3.1.x/4.1.x User Guide
Switch Information Field Descriptions
The Switch Information fields are described in Table 18 .
Table 18: Switch Information Field Descriptions
Field Description
Name and ID
Name Display or modify the current switch name. The switch name
can be from 1 to 15 characters in length.
Domain ID Displays or sets switch domain ID. Domain IDs must be
unique within a fabric. Domain ID can only be modified
when the switch is disabled. The switch must be disabled to
change domain ID.
To change domain ID, enter new domain ID in this field.
■
Use a number from 1 to 239 for normal operating mode
(FCSW compatible)
■
Use a number from 0 to 31 for VC encoded address
format mode (backward compatible to StorageWorks
Fibre Channel Switches 8 and 16).
Manufacturers
Serial #
Displays the Manufacturer serial number of the switch (Read
only).
Supplier Serial # Displays the Supplier serial number of the switch, if
applicable (Read only).
Switch Status
Enable / Disable
Select the Enable radio button to enable the switch, or the
Disable radio button to disable the switch.
View Report Click this button to view a report of the selected switch.
Email Configuration
DNS Server 1 Display or modify the first DNS Server name.
DNS Server 2 Display or modify the second DNS Server name.
Domain Name Display or modify the Domain name of the DNS Server.
