Introducing HP Web Tools
29 Web Tools Version 3.1.x/4.1.x User Guide
Note: The Switch View status is updated approximately once every 15 seconds. The
Fabric Tree status is updated approximately every 30 seconds. However, the initial
display of the Switch Explorer may take from 30 to 60 seconds after the switch is
booted.
Note: For all status displays that are based on errors per time interval, errors will not
cause the status to change to faulty until the entire sample interval has passed.
An example of the Fabric Tree is displayed in Figure 2 .
Figure 2: Fabric Tree
Fabric Management Toolbar
The Fabric Management toolbar enables you to access fabric-wide administration
tasks quickly and easily. An example of the Fabric Management Toolbar is shown
in
Figure 3 .
Figure 3: Fabric Management Toolbar
The following options are available through the Fabric Management toolbar:
