Switch Explorer View
54 Web Tools Version 3.1.x/4.1.x User Guide
Switch Graphic Buttons
There are a number of buttons beneath the Switch Graphic which enable you to
access various configuration and monitoring functions for the switch. Some of
these buttons may require a license key to activate. If the appropriate license key is
not installed for a particular feature, that button may not appear in the Switch
Graphic display. The buttons available from the Switch Graphic are described in
Table 7 .
Table 7: Switch Panel Buttons
Switch Panel
Button Description
Status: Healthy Select to open Switch Status View, which displays the overall
status of the selected switch (for information about this view,
see “ Using the Switch Status Button ” on page 66). The
background color indicates the switch status. Each color
indicates a different operational state:
■
Green - Healthy
■
Yellow - Marginal (mix of good and faulty readings)
■
Red - Down (more than two faulty readings)
■
Gray - Unknown or unmonitored
If no data is available from a switch, the most recent
background color remains displayed.
Events Select to open Switch Events View to display the switch events
log (for information about this view, see “ About the Switch
Events Button ” on page 67).
Admin Select to open Switch Administration View (for information
about this view, see “ Switch Admin Window ” on page 91).
Telnet Select to launch the Fabric OS command line interface for the
switch (for information about this view, see “ About the Telnet
Button ” on page 71).
