HP StorageWorks MSA 2.8 SAN Switch - Manual (Page 102)

Switch Admin Window
102 Web Tools Version 3.1.x/4.1.x User Guide
Using the Network Config Tab
Use the Network Config tab to configure Ether
Configuring an Ethernet IP or FC IP Address
1. Access the Switch Admin Window (see “ About the Switch Admin Window ”
on page 92).
2. Enter the admin user name and password.
3. Select the Network Config tab.
4. Select the Ethernet or Fibre Channel IP address you want to configure.
Note: If both the Fibre Channel IP and Ethernet IP are present, the switch is identified
by the Fibre Channel IP.
5. Enter an Ethernet or Fibre Channel address in the appropriate field (for
example, 123.123.123.123).
6. Click the Apply button.
Configuring a Syslog IP Address
1. Access the Switch Admin Window (see “ About the Switch Admin Window ”
on page 92).
2. Enter the admin user name and password.
3. Select the Network Config tab.
4. Enter a non-null IP address in one of the Syslog IP fields (for example,
123.123.123.123).
5. Click the Add button. The configured IP is displayed in the Syslog IP
window.
6. Click the Apply button.
