Port Management
255 Web Tools Version 3.1.x/4.1.x User Guide
About the Port Information View
The following information appears at the top of the Port Information window,
regardless of which tab is selected:
The Port Information View provides the following tabs for each port:
■ Port Stats Tab—Provides information about transmission speed, reception
speed, and the volume of traffic through the selected port.
■ SFP Tab—Provides information about the SFP (Small form factor pluggable)
installed in the selected port. The information displayed depends on the type
of SFP installed.
■ Loop Tab—Provides information about any loop on the selected port.
PortStats Tab Example
An example of the PortStats tab is shown in Figure 58 .
Table 62: Port Information Window
Field Description
Port Name Displays the port name.
Port WWN Displays the WWN assigned to the port.
Port Module Displays the type of SFP.
Port Status Displays the status of the port.
Port Type Displays the type of port, such as U_Port or E_Port.
