Switch Explorer View
56 Web Tools Version 3.1.x/4.1.x User Guide
Temperature Select to display the temperature status of the chosen switch.
For more information, see “ About the Temp Button ” on
page 82.The background color indicates the temperature
status. Each color indicates a different operational state:
■
Green - Healthy
■
Yellow - Marginal
■
Red - Down
■
Gray - Unknown or unmonitored
If no data is available from a switch, the most recent
background color remains displayed.
Power Select to display the power status of the selected switch. For
more information, see “ About the Power Button ” on page 83.
The background color indicates the power status. Each color
indicates a different operational state:
■
Green - Healthy
■
Yellow - Marginal
■
Red - Down
■
Gray - Unknown or unmonitored
If no data is available from a switch, the most recent
background color remains displayed.
Hi Avail Select to display the Hi-Availability window. The Hi
Availability feature enables you to perform CP failover
without disrupting traffic on the switch. Hi Availability
requires that you maintain synchronization of services on
each CP.
Table 7: Switch Panel Buttons (Continued)
Switch Panel
Button Description
