HygroGen2 Humidity and Temperature Generator:
Instruction Manual
Appendix
Instruction Manual for Software
Version 2.1
Document Type
Page 64 of 75
Document title
Service & Consumables
HG2-SERVICE
HygroGen2 service, recommended at 12 month intervals. Warranty period then extended by 12
months
HG2-LABOUR
On-site service and training, per day, excludes 40p per mile and expenses incurred at cost
HG2-DES-3
Molecular sieve desiccant (3 kg)
xx Diameter codes for customised diameters
0
No probe ports
1
15 mm (HygroClip)
2
20 mm
3
25 mm
4
10 mm
5
5 mm
6
12 mm
7
18 mm
8
30 mm
9
Cable gland to accept 9…17 mm diameter probes
A
6 mm
B
4 mm
C
22 mm
D
23 mm
E
13 mm
F
19 mm
G
21mm
H
18.5 mm (Vaisala HMP45AD)
I
18.2 mm (Aanderaa 3445)
J
9 mm
K
19.75 mm (no 'O' rings)
L
Cable gland to accept 3 - 7 mm diameter probes
M
12.7 mm
N
6.35 mm (1/4 inch)
O
not used
P
3 mm
Q
not used
R
13.5 mm
S
26 mm
T
34 mm
U
14 mm
V
20 mm cable gland 5 -12 mm probes
W
32 mm cable gland 11-21mm probes
X
not used
Y
15 mm angled Vaisala HMDW40/W50
Z
not used
