Page 53: E-m-hg2-s-v2.1

E-M-HG2-S-V2.1

Rotronic AG

Bassersdorf, Switzerland

Document code

Unit

HygroGen2: Humidity and Temperature Generator

with AutoCal/AutoCal+, Remote Control and

Range Extensions options.

Instruction Manual

Instruction Manual for Software

Version 2.1

Document Type

Page 49 of 75

Document title

6 HW4 Embedded

HygroGen2 comes with HW4 ROTRONIC device control software on its embedded PC. This provides

the user with access to HW4 functionality to access ROTRONIC USB devices without the need for a

separate PC.

HW4 features include:

• Psychrometric conversions

• Instrument configuration

• Data acquisition

• Measurement display and graphing

• Calibration and adjustment

HW4 does not work with other manufacturers’ USB probes.

6.1 HW4 Set Up and Getting Started

For full functionality, HW4 requires an external monitor, keyboard and mouse to be connected to the

HygroGen2 (see

). To start HW4, touch the HW4 icon. Drag the HW4 window onto a second

monitor if available.

Any ROTRONIC USB probes that are connected to the HygroGen2’s USB ports can be connected to

HW4 using the “Search for USB Masters” command. For a full overview of the use and features of

HW4, please refer to the full HW4 manual. This can be obtained from the Downloads section of

6.2 HW4 Installation and Registration

HW4 is preinstalled and activated during HygroGen2 manufacture. The unique HW4 serial key number

for the machine can be identified via HG Info button on the Settings screen of the HygroGen2; please

have this information available in the event that you require technical support.

To register your HW4 software and to assign your full contact details, visit www.rotronic.com and go

to the “Software” Section. Software registration will ensure that you receive full support and

notification of upgrades available.
