The IP address assigned to your instrument will be reported in the Network Settings interface and via
the “HygroGen2 Info” screen. The HygroGen2 will assign itself a network name/identity. This can be
changed within the interface. It is recommended to change it to the instrument’s serial number, though
local network policies may require something else.
Operation of the Remote Control functionality is described in section 4.3 .
3.3.2 Date and Time Settings
Date and time stamps are included in AutoCal and HW4 logged data.
To adjust these settings, select the “Date and Time” option from the “Settings” drop-down menu on the
“Settings and Updates” screen.
3.3.3 Touch Screen Calibration
Should the touch screen calibration be significantly awry – which can happen when upgrading from
version 1.x to version 2.0 – you can realign the touch screen calibration. You may wish to plug in a USB
mouse to perform this step.
Select the “Touch Screen” option from the “Settings” drop-down menu on the “Settings and Updates”
screen. Pressing the touch screen button will begin a four-point calibration. Press the cross in each
corner of the screen as directed.
3.3.4 Activation of Enhanced Features
Enhanced Features can be activated via the “Upgrade Features” option on the “Updates” drop-down
menu in Configuration Mode, or via the Settings screen in Standard Operation Mode. See section 4 for
more details.
Figure 6: Date and Time Properties
