B4: HygroGen2 Order Codes
HYGROGEN2
HG2-S
HygroGen2 with touch screen, calibrated control/reference probe, set-point control &
programmer function, heated sample loop, desiccant cell, fill syringe, embedded HW4-P
software. Order chamber door separately
Chamber doors / probe sleeves / bungs
HG2-D-11111
HG2 door 5 x 15 mm ports (for 5 HygroClips) with 5 bungs, order specific B1 sleeves for smaller
probe diameters
HG2-D-888888
HG2 door 6 x 30 mm ports with 6 bungs, order specific B8 sleeves to suit smaller probe
diameters
HG2-D-HFW
HygroGen2 probe door for HF3 and HF4 wall mount transmitters, also HP21 hand held with fixed
probe
HG2-DP-00000 HG2 clear acrylic door (no ports) for instruments with displays
HG2-B1 15 mm Bung for HG2-D-11111
HG2-B1-xx
B1 probe sleeves for HG2-D-11111 (15 mm external, internal probe diameter see xx diameter
codes)
HG2-B8 30 mm Bung for HG2-D-888888
HG2-B8-xx
B8 probe sleeves for HG2-D-888888 (30 mm external, internal probe diameter see xx diameter
codes )
HG2-D-xxxxx HG2 fully custom door for > 30 mm ports, see xx diameter codes
HG2-Bxx Custom bung
HG2-Bxx-xx Custom probe adaptor sleeves (all types)
HG2-D-888888-Map HG2-D888888 door with detachable mapping rig
Optional Enhanced Features
HG2-V2.X.UPGRADE
HG2-V2.x Software and HW4-V3.x upgrade USB stick (activation codes must be purchased
separately)
HG2-AutoCal-Code HG2 AutoCal function, activation code
HG2-AutoCal+-Code AutoCal+ - extension to enable MBW chilled mirror as external reference. NB Requires AutoCal
HG2-Remote-Code LAN Remote Control
HG2-TempExt-Code HG2 Low temperature range extension -5…60 °C, activation code
HG2-HumiExt-Code HG2 Humidity range extension 2…99 %rh, activation code
HG2-EF-Bundle1 Enhanced Feature Bundle 1 [Temperature/Humidity/AutoCal], activation code
HG2-EF-Bundle2 Enhanced Feature Bundle 2 [AutoCal/AutoCal+/Remote], activation code
HG2-EF-Bundle3 Enhanced Feature Bundle 3 [Temperature/Humidity/Remote/AutoCal/AutoCal+], activation code
Spares
HG2-DC Additional desiccant cell, pre-filled with molecular sieve
HG2-FILL Fill tube and syringe
HC2-S
Standard control or reference probe. Order UKAS temperature and humidity calibration
separately
Accessories
HG2-TB HygroGen2 transit bag, lightweight
HG2-TC HygroGen2 heavy-duty transit case
HG2-MON DVI monitor and lead
HG2-DVIC DVI lead
HG2-AC3001-L/050 HygroClip2 calibration cable, 50 cm, USB
HG2-AC3001-L/050 (5) HygroClip2 calibration cable, 50 cm, USB. Bundle of 5 pieces HG2-AC3001-L/050
HG2-PRT-ring PRT mounting ring for permanent monitoring of HG2 using external temperature reference
