■ Special Command
Command to exchange data between Transmitter and Receiver.
＜ Special Command List ＞
№ Special Command Command Value Command Direction Response
(1) Signal Tower Information 0x00 Transmitter → Receiver (Host） ×
(2) Change Transmitter Mode Setting 0x40 Receiver (Host）→ Transmitter ○
(3) Change Transmitter Wireless Setting 0x50 Receiver (Host）→ Transmitter ○
(4) Obtain Transmitter Wireless Setting 0x70 Receiver (Host）→ Transmitter ○
(5) Receiver Contact Controller 0x30 Host → Receiver ○
(1) 0x00 ：Signal Tower Information
P_Cmd
Special Data
Fixed
Signal Tower Condition Data Error Code
0x00 0x00 0x00
1 byte 2 bytes 2 bytes 1 byte
① ②
① Signal Tower
Condition Data
： Every 3 bits indicates information for Red, Yellow, Green, Blue and White.
bit 15 ：Open（0 Fixed）
bit 14-12 ：Red Information
bit 11-9 ：Yellow Information
bit 8-6 ：Green Information
bit 5-3 ：Blue Information
bit 2-0 ：White Information
（Binary 3 bit Condition） bit Condition Signal Tower Condition
000 Unimplemented
001 Off
010 On
100 Flashing
② Error Code ： 0x00 ：No Error
0x22 ：If information for "Flashing Status" was not previously
carried out, anything outside the indication above is a "Fail" status.
